Shimano Tiagra FC-4700 10-speed Chainring

The Shimano Tiagra 10-speed chainring is a high-quality replacement part designed for Tiagra FC-4700 cranksets. Ideal for 2x setups with 34-50 and 36-52 chainring combinations (110 mm BCD), this durable chainring ensures smooth shifting and reliable performance. The small rings are crafted from lightweight aluminum, while the larger ones feature a robust aluminum-plastic composite for added strength and longevity. Perfect for riders seeking seamless efficiency on the road.

SPECIFICATIONS

Application: Road, City
Mount: 110 mm pitch circle, 4-arm asymmetrical
Teeth: 34 t, 36 t, 50 t, 52 t
Gearing: 2x10-speed

Technical Information:
Combinations: 34-50 t, 36-52 t
Material: aluminium (34 + 36 t), aluminium/composite (GFRP 50 t + 52 t)

Compatibility:
- Tiagra FC-4700

Features:
- anodised

Models:
34 tooth: 45g
- Type: MK
- Manufacturer Part Number: Y-1RC34000

36 tooth: 55g
- Type: ML
- Manufacturer Part Number: Y-1RC36000

50 tooth: 80g
- Type: MK
- Manufacturer Part Number: Y-1RC98050

52 tooth: 90g
- Type: ML
- Manufacturer Part Number: Y-1RC98060

Note to Type Designation:
The type designations (with one or two letters) indicate that the chainrings can be combined with each other. Since the large rings have specially shaped teeth and shifting aids that make it easier for the chain to climb, full shifting performance is only guaranteed with matching small rings - and vice versa. A chainring of type XY should therefore only be ridden with a chainring of type XY. The same applies to all other types.

Contents:
- 1 x Shimano Tiagra FC-4700 chainring



FAQ

Can I change the chainring on my Shimano TIAGRA 10 speed ROAD crankset?
Yes, the Shimano TIAGRA 10 speed ROAD chainring is exchangeable by P.C.D. 110 mm.

What chainring combinations are available for the Shimano TIAGRA 10 speed ROAD chainring?
The Shimano TIAGRA 10 speed ROAD chainring combinations are 48-34T, 50-34T and 52-36T.

What chain is compatible with the Shimano TIAGRA 10 speed ROAD chainring?
The Shimano TIAGRA 10 speed ROAD chainring is compatible with chain HG-X 10 speed.
